The REP25 features an efficient and streamlined design that accommodates bed-heights from 37 to 49 inches.
Lightweight and compact, the REP25 is more than capable with 2,500 pounds of lifting capacity.
Power Down comes standard on the REP25 and offers consistent movement of the platform when lowering.
Coming in at only 505-516 lbs, the REP25 packs a powerful 2,500-lb lifting capacity in a lightweight, modern design.
2-piece, 37-inch-deep, plus a 4" front and 4" back taper, extruded aluminum platform (w/ 19.5" base and 17.5" flipper)
2-piece, 41-inch-deep, plus a 4" front and 4" back taper, extruded aluminum platform (w/ 21.5" base and 19.5" flipper)
Secured on underside of liftgate, visible when lift is stored or in use
a fixed, side control panel to operate the liftgate
12-foot, two-function corded pendant control with socket.
39-foot, 2-gauge, full length power cable
consistent movement of platform when lowering
292 pound, 12.6-inch deep, reinforced steel bed-extension; with 21 - 35-inch, bolt-on side steps, including rubber dock bumpers.
318 pound, 12.6-inch deep, reinforced steel bed-extension; with 21 - 35-inch, bolt-on side steps, including rubber dock bumpers.
85 pound, steel bumper bar
used to secure wheeled cargo (loses 4-inches of loading depth when deployed)
flashing lights on platform when liftgate is activated
foot activated controls on liftgate platform for hands-free operation
disables power to the liftgate along the power line
